CS902S
90cm SS Canopy rangehood
A 90cm stainless steel canopy rangehood with slide controls
Key Features
- Stainless steel finish
- Slide controls
- 3 fan speed options
- Auto thermal cutout safety switch
- Optional carbon filter(s)
- Recirculating option (Kit AR500RK)
- Optional Extra Length Flue Cover (AR500FS)
PRODUCT PROFILE
- Domestic warranty details (yrs)
- 2
- Type of Rangehood
- wall mounted canopy
- Design family (eline)
- Chef
- Nominal width
- 90
MOTOR/FAN
- Number of fans speeds
- 3
- Variable speed control
- No
- Type of motor
- centrifugal
- Maximum airflow M3/Hr
- 550
- Noise level dB high
- 55
- Noise level dB low
- 48
DIMENSIONS
- Diameter of ducting (mm)
- 125
- Minimum installation height from cooking surface Gas (mm)
- 650
- Minimum installation height from cooking surface Electric (mm)
- 650
- Maximum canopy chimney height (mm)
- 1240
- Flue cover depth (mm)
- 165
- Flue cover width (mm)
- 222
CONTROLS
- Control panel
- switch and slide
- Safety/ display indicators
- auto thermal cutout safety switch
